Intelligent Modular Online UPS System:
This system delivers high efficiency, with a main road mode efficiency of ≥96.5% and a battery mode efficiency exceeding 96.5%. It features an intuitive display with an LCD+LED interface and a 7-inch color touchscreen, providing easy navigation and clear monitoring. The system complies with stringent safety standards, including IEC62040-1 and IEC60950-1, ensuring reliability and protection. It also adheres to EMC regulations such as IEC62040-2 and various immunity standards like IEC61000-4-2 (ESD), IEC61000-4-3 (RS), IEC61000-4-4 (EFT), and IEC61000-4-5 (Surge).
With an IP20 protection grade, the system is built to endure typical operational environments. Standard features include USB, RS232, RS485 interfaces, a dry contact card, and battery cold start capabilities, while optional accessories like SNMP cards, extended dry contact cards, parallel components, LBS, and connectivity options like APP/WiFi/Bluetooth are available for enhanced functionality.
The system operates within a temperature range of 0-40°C and can be stored at temperatures from -25°C to 70°C, with a humidity range of 0-95% (non-condensing). It operates with noise levels of 65dB at 100% load and 62dB at 45% load, ensuring minimal disruption in sensitive environments.
Three-Phase Online UPS Working Mode:
| 3-Phase Input, 3-Phase Output | 3-Phase Input, Single-Phase Output |
| Single-Phase Input, Single-Phase Output | Double-Conversion Online Mode |
120KVA Intelligent Modular UPS Monitoring System：
Battery Internal Resistance Monitoring Function
To maximize battery safety and lifespan, the UPS can be equipped with optional accessories to monitor the voltage, internal resistance, temperature, and other parameters of each individual battery. These details can be displayed in real time on the UPS screen (optional).
Core Component Temperature Monitoring Function
Real-time temperature monitoring is performed on the key heating components of each power module, including rectifier three-phase IGBT temperature, inverter three-phase IGBT temperature, inlet temperature, outlet temperature, etc. At least 8 temperature measurement points can be visually displayed, and self-aging verification can be conducted.
Environmental Monitoring Function for the Data Center
Supports 4 temperature and humidity channels, 2 leakage detection channels, 2 smoke detection channels, and 4 sets of individual battery monitoring.
Powerful Local Storage Function
100,000 records technical description: The UPS screen integrates a 128M Flash memory, supporting the storage of at least 100,000 local historical records and data. It also supports an external SD card to enable unlimited data storage.
Intelligent Modular UPS With LED Screen Usage Scenarios:
UPS systems are widely used across various industries, including government, finance, telecommunications, education, transportation, meteorology, broadcasting, taxation, healthcare, and energy.
1.In government, UPS systems support critical infrastructure such as security and communication systems.
2.In finance, they protect banking systems and online transactions, ensuring continuous service.
3.Telecommunications rely on UPS to maintain network stability and communication services.
4.Education institutions use UPS to safeguard IT systems, including servers and online learning platforms.
5.In transportation, UPS ensures the operation of traffic control systems and ticketing machines.
6.Meteorology benefits from UPS in ensuring continuous weather monitoring and forecasting.
7.Broadcasting uses UPS to prevent downtime in live broadcasts and transmission.
8.For taxation, UPS systems secure the operation of online tax systems and data processing.
9.In healthcare, UPS protects sensitive medical equipment and hospital IT infrastructure.
10.Energy sector applications include securing power distribution systems and ensuring uninterrupted service.
